commutateur réseau Géré 2.5G Ethernet (100/1000/2500) Gris

QSW-M2108-2S - commutateur réseau Géré 2.5G Ethernet (100/1000/2500) Gris

Ref : QSW-M2108-2S
332,93 €
HTVA
Taxe Ecotrel : 0,05 €
SKU
QSW-M2108-2S
Marque
Catégorie
Switch Commutateurs réseaux

Webmanged 8Port SwitcH 2.5Gbps 2 Port 10Gbps SFP+

Points Clés
- Compliant with IEEE 802.3az Energy Efficient Ethernet and IEEE802.3x Flow Control in full-duplex mode, the QSW-M1208-8C avoids packet loss from unparalleled bandwidth and reduces power consumption for low-speed and inactive connections
- Includes two 10GbE SFP+ ports and eight 2.5GbE RJ45 ports for connecting various devices and enabling hybrid high-speed networks
- One of the few web-managed switches that supports Rapid Spanning Tree Protocol (RSTP). Easily and efficiently deploy small/medium-scale networks that support expansion, redundancy, and loop prevention
- Provides Layer 2 management features (such as LACP, VLAN, ACL and LLDP) for IT staff to efficiently control network bandwidth and enhance security
- QSS can be updated with just one click, helping IT staff ensure their network security
- The QNAP Switch System (QSS) is easy to use and provides an overview dashboard, port management and setting guide, making central network management intuitive

commutateur réseau Géré 2.5G Ethernet (100/1000/2500) Gris
QSW-M2108-2S
QNAP QSW-M2108-2S. Type de commutateur: Géré. Type de port Ethernet RJ-45 de commutation de base: 2.5G Ethernet (100/1000/2500), Quantité de ports Ethernet RJ-45 de commutation de base: 8, Port de console: RJ-45. Full duplex. Répertoire MAC: 16000 entrées, Capacité de commutation: 80 Gbit/s. Standards réseau: IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE...
Caractéristiques de gestion
Type de commutateurGéré
Gestion basée sur le webOui
Connectivité
Quantité de ports Ethernet RJ-45 de commutation de base8
Type de port Ethernet RJ-45 de commutation de base2.5G Ethernet (100/1000/2500)
Port de consoleRJ-45
Réseau
Standards réseauIEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
Soutien 10GOui
Technologie de câblage Ethernet cuivre100BASE-T,1000BASE-T
Full duplexOui
Assistance contrôle des fluxOui
Protocles Spanning Tree (STP)Oui
Support VLANOui
Fonctions LAN virtuellesTagged VLAN
Fibre optique
Technologie de câblage Ethernet sur fibre1000BASE‑LX,1000BASE‑SX
Transmition des données
Répertoire MAC16000 entrées
Capacité de commutation80 Gbit/s
Support de trames étendues (Jumbo Frames)Oui
Trames géantes9000
Design
Couleur du produitGris
Bouton de réinitialisationOui
VoyantsActivité, Liaison, Énergie, Vitesse, Statut
Nombre de ventilateurs1 ventilateur(s)
CertificationCE, FCC, VCCI, BSMI
Puissance
Tension d'entrée AC100 - 240 V
Fréquence d'entrée AC50/60 Hz
Consommation (max)23 W
Conditions environnementales
Température d'opération0 - 40 °C
Humidité relative de fonctionnement (H-H)5 - 95%
Poids et dimensions
Largeur290 mm
Profondeur127 mm
Hauteur42,5 mm
Poids1,12 kg
Informations sur l'emballage
Poids du paquet1,52 kg
