PEXUSB311AC3 - StarTech.com PEXUSB311AC3 carte et adaptateur d'interfaces Interne USB 3.2 Gen 2 (3.1 Gen 2)
Ref : PEXUSB311AC360,40 €
HTVAEn Stock
LIVRAISON LUXEMBOURG : 1-2 JOURS OUVRABLES !
StarTech.com Carte PCIe à 2 ports - USB-A et USB-C, 10 Gbps - Adaptateur de carte contrôleur hôte - Carte d'extension PCIe USB 3.2 Gen 2x1 - Adaptateur USB - PCIe 3.0 x4 - USB-C 3.1 x 1 + USB 3.1 Gen 2 x 1 - pour P/N: S251BMU313, S251BPU313, S252BU313R
Points Clés
- COMPATIBILITY: Installs in full or low-profile PCIe 3.0 x4 desktop/server slot (lower performance w/PCI-e 2.0)- Windows/Linux/macOS auto driver install (Windows 8 &- up)- Works with USB 3.2/3.1/3.0/2.0_x000D_
- HIGH PERFORMANCE: USB 3.1 Gen 2 or USB 3.2 Gen 2x1 PCIe Add-On card supports Multiple INs, maintains max bandwidth even when mixed speed devices are connected- 10Gbps per port- 1x USB-A &- 1x USB-C_x000D_
- MAX PERFORMANCE WITH USB DEVICES: 2-port USB-A &- USB-C PCIe card adapter supports USB Attached SCSI Protocol (UASP) optimizing USB performance w/ external storage devices like SSDs, HDDs, NVMe drives_x000D_
- POWER: Expansion card w/ SATA power supplies supplemental power to the USB ports (when motherboard power is insufficient) providing up to 5V 3A/15W via the USB-C port &- 5V 0.9A/4.5W via the USB-A port_x000D_
- THE STARTECH.COM ADVANTAGE: StarTech.com offers a 2-year warranty &- free lifetime 24 hour support on this dual port USB-A &- USB-C PCI Express Host Controller card w/ full &- low profile bracket incl._x000D_
- _x000D_
Points Clés
- COMPATIBILITY: Installs in full or low-profile PCIe 3.0 x4 desktop/server slot (lower performance w/PCI-e 2.0)- Windows/Linux/macOS auto driver install (Windows 8 &- up)- Works with USB 3.2/3.1/3.0/2.0_x000D_
- HIGH PERFORMANCE: USB 3.1 Gen 2 or USB 3.2 Gen 2x1 PCIe Add-On card supports Multiple INs, maintains max bandwidth even when mixed speed devices are connected- 10Gbps per port- 1x USB-A &- 1x USB-C_x000D_
- MAX PERFORMANCE WITH USB DEVICES: 2-port USB-A &- USB-C PCIe card adapter supports USB Attached SCSI Protocol (UASP) optimizing USB performance w/ external storage devices like SSDs, HDDs, NVMe drives_x000D_
- POWER: Expansion card w/ SATA power supplies supplemental power to the USB ports (when motherboard power is insufficient) providing up to 5V 3A/15W via the USB-C port &- 5V 0.9A/4.5W via the USB-A port_x000D_
- THE STARTECH.COM ADVANTAGE: StarTech.com offers a 2-year warranty &- free lifetime 24 hour support on this dual port USB-A &- USB-C PCI Express Host Controller card w/ full &- low profile bracket incl._x000D_
- _x000D_
- HIGH PERFORMANCE: USB 3.1 Gen 2 or USB 3.2 Gen 2x1 PCIe Add-On card supports Multiple INs, maintains max bandwidth even when mixed speed devices are connected- 10Gbps per port- 1x USB-A &- 1x USB-C_x000D_
- MAX PERFORMANCE WITH USB DEVICES: 2-port USB-A &- USB-C PCIe card adapter supports USB Attached SCSI Protocol (UASP) optimizing USB performance w/ external storage devices like SSDs, HDDs, NVMe drives_x000D_
- POWER: Expansion card w/ SATA power supplies supplemental power to the USB ports (when motherboard power is insufficient) providing up to 5V 3A/15W via the USB-C port &- 5V 0.9A/4.5W via the USB-A port_x000D_
- THE STARTECH.COM ADVANTAGE: StarTech.com offers a 2-year warranty &- free lifetime 24 hour support on this dual port USB-A &- USB-C PCI Express Host Controller card w/ full &- low profile bracket incl._x000D_
- _x000D_
StarTech.com PEXUSB311AC3 carte et adaptateur d'interfaces Interne USB 3.2 Gen 2 (3.1 Gen 2)
PEXUSB311AC3StarTech.com PEXUSB311AC3. Interface de l'hôte: PCIe, Interface de sortie: USB 3.2 Gen 2 (3.1 Gen 2), Facteur de forme de carte d’extension: Hauteur totale / Profil bas. Couleur du produit: Rouge, Temps moyen entre pannes: 2684396 h, Certification: Microsoft WHQL, CE, FCC, REACH. Jeu de composants: ASMedia - ASM3142, Taux de transfert de données (max): 10 Gbit/s. Prise en charge du système d'exploitation Windows: Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10..., Prise en charge du système d'exploitation Mac: Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Prise en charge du système d'exploitation serveur: Windows Server 2008 R2,Windows Server 2012,Windows Server 2016,Windows Server 2019. Largeur: 81 mm, Profondeur: 120 mm, Hauteur: 19 mm
| Connectivité | |
| Interface de l'hôte | PCIe |
| Interface de sortie | USB 3.2 Gen 2 (3.1 Gen 2) |
| Facteur de forme de carte d’extension | Hauteur totale / Profil bas |
| Standard de carte d’extension | PCIe 3.0 |
| Quantité de ports de type A USB 3.2 Gen 2 (3.1 Gen 2) | 1 |
| Quantité de ports de type C USB 3.2 Gen 2 (3.1 Gen 2) | 1 |
| Design | |
| Interne | Oui |
| Couleur du produit | Rouge |
| Temps moyen entre pannes | 2684396 h |
| Certification | Microsoft WHQL, CE, FCC, REACH |
| Caractéristiques | |
| Jeu de composants | ASMedia - ASM3142 |
| Taux de transfert de données (max) | 10 Gbit/s |
| Support UASP | Oui |
| Conditions environnementales | |
| Température d'opération | 5 - 50 °C |
| Température hors fonctionnement | -20 - 85 °C |
| Taux d'humidité de fonctionnement | 20 - 80% |
| Configuration minimale du système | |
| Prise en charge du système d'exploitation Mac | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur |
| Prise en charge du système d'exploitation Linux | Oui |
| Prise en charge du système d'exploitation serveur | Windows Server 2008 R2,Windows Server 2012,Windows Server 2016,Windows Server 2019 |
| Détails techniques | |
| Certificats de durabilité | RoHS |
| Poids et dimensions | |
| Largeur | 81 mm |
| Profondeur | 120 mm |
| Hauteur | 19 mm |
| Poids | 48 g |
| Informations sur l'emballage | |
| crochets d'élévation inclus | Oui |
| Guide d'installation rapide | Oui |
| Largeur du colis | 170 mm |
| Profondeur du colis | 142 mm |
| Hauteur du colis | 30 mm |
| Poids du paquet | 123 g |
| Données logistiques | |
| Largeur du carton principal | 37 cm |
| Longueur du carton principal | 36,5 cm |
| Hauteur du carton principal | 50 cm |
| Quantité par carton principal | 60 pièce(s) |
